Muab ob npaug rau PE Daim Ntawv Khob Tshuab Chaw Tsim Tshuaj - Sini Machinery
Sini Machinery tsim thiab tsim kev lag luam- qib Ob chav PE Daim Ntawv Khob Tshuab tsim ua haujlwm tas mus li, siab - ntim ntau lawm ntawm ob npaug -coated ntawv khob. Cov tshuab no tau ua kom zoo rau cov dej txias, dej khov, thiab cov khoom ntim khov khov uas yuav tsum muaj kev tiv thaiv dej noo thiab ntev - lub sij hawm kev ncaj ncees yuav tsum tau.
Ua raws li qhov hnyav- lub luag haujlwm txhawb nqa lub tshuab chassis, peb cov tshuab synchronizes precision ntawv pub, ultrasonic lossis ntau- cheeb tsam thermal sealing, thiab automated hauv qab tsim kom tshem tawm cov kev sib dhos thiab xyuas kom muaj qhov sib xws ntawm cov khoom siv txuas ntxiv.
Dab tsi yog Ob Chav PE Daim Ntawv Khob Ua Tshuab?
Ob chav PE Paper Cup Forming Tshuab yog cov cuab yeej siv los tsim cov khob ntawv coated nrog polyethylene ntawm ob sab hauv thiab sab nrauv.
Cov qauv no yog tsim tshwj xeeb rau cov ntawv thov uas yuav tsum tau muaj kev tiv thaiv noo noo thiab kev tiv thaiv condensation, tshwj xeeb tshaj yog nyob rau hauv cov dej txias thiab khov khoom ntim.
Thaum lub sij hawm tsim khoom, cov ntaub ntawv tshuab, ntsaws ruaj ruaj, thiab cov duab PE-coated ntawv nyob rau hauv kev tswj kub thiab siab tej yam kev mob los tswj txheej kev ncaj ncees thiab khob qauv stability.
Piv nrog rau cov txheej txheem ntawv khob tsim tshuab, ob chav PE ntau lawm yuav tsum muaj kev sib koom tes siab dua hauv peb qhov chaw:
• Thermal balance control thaum lub sij hawm sealing los tiv thaiv txheej txheej
• Siab synchronization thaum lub sij hawm tsim kom muaj lub khob zoo ib yam
• Cov qauv ruaj khov thaum lub caij txias kom ruaj khov tom qab sib khi
Lub tshuab integrates pub, sib sau, hauv qab sealing, curling, thiab stacking rau hauv ib tug nruam automated ntau lawm txheej txheem.
Technical Specifications
Peb cov tshuab siv lub tshuab PLC zoo heev los ua kom sib haum xeeb rau txhua qhov kev txav. Hauv qab no yog cov qauv kev ntsuas kev ntsuas rau peb cov khoom lag luam:
|
Parameter |
Specification Range / Standard |
|
Tau tshaj cov ntaub ntawv |
150-380gsm (Ob chav PE Coated / Laminated Paperboard) |
|
Khob Size Capacity |
2 oz - 16 oz (Customizable pwm configurations muaj) |
|
Kev Tshaj Tawm Ntau Lawm |
60 - 120 pcs / min (Tswj los ntawm lub khob qhov ntev thiab daim ntawv hnyav) |
|
Kev siv zog tag nrho |
6 kW-12 kW |
|
Kev Siv Hluav Taws Xob |
380V / 220V, 50Hz / 60Hz (Configured rau hauv cheeb tsam daim phiaj) |
|
Pneumatic Cua Siab |
0.4-0.6MPa |
|
Net Tshuab Nyhav |
2,600-3,400 kg |
|
Tswj Architecture |
Synchronized PLC System nrog Touchscreen HMI |
|
Lubrication System |
Automated Centralized Roj Pub |
Cov yam ntxwv tseem ceeb
Cov Khoom Siv Lub Tshuab Muaj Zog
Hnyav- lub luag haujlwm steel thav duab tsim txo kev co thaum lub sijhawm ua haujlwm, txhawb kev ruaj khov tsim raug hauv kev tsim khoom tas mus li.
Synchronized Cam Transmission System
Txhua qhov chaw nres tsheb ua haujlwm hauv kev sib koom ua ke, ua kom muaj kev hloov pauv ntawm kev sib sau, kev sib khi, thiab cov txheej txheem tso tawm.
Ob chav PE Thermal Control System
Multi- cheeb tsam cua sov tswj xyuas kom ruaj khov sealing kub faib thiab tiv thaiv coated nto thaum lub sij hawm sib txuas.
Stable hauv qab Sealing Unit
Hauv qab sealing siab yog tswj hwm los xyuas kom muaj kev ruaj ntseg khob hauv paus tsim thiab lub zog muaj zog.
Automatic Cup Collection System
Cov khob tiav lawm tau muab tso ua ke thiab muab tso ua ke kom txhawb nqa cov khoom ntim qis qis.
Kev Tsim Kho Kev Ua Haujlwm Nruam
Lub kaw lus tau ua kom zoo rau ntev - voj voog ntau lawm nrog kev ua haujlwm ruaj khov thiab txo cov kev hloov kho.
Tshuab ua hauj lwm txheej txheem
Lub tshuab ua haujlwm los ntawm kev ua haujlwm txuas ntxiv txuas ntxiv:
Daim ntawv pub thiab tso chaw
Muab ob npaug rau PE coated ntawv blanks tau cia li pub nrog kev tswj xyuas kom meej kom ntseeg tau tias qhov chaw nkag mus zoo ib yam.
Sidewall tsim thiab sealing
Daim ntawv yog tsim rau hauv ib lub cylindrical qauv thiab kaw siv tswj thermal bonding thaum khaws cia txheej kev ncaj ncees.
Hauv qab daim ntawv tso
Cov ntawv hauv qab yog qhov raug muab tso rau kom ntseeg tau tias kev sib haum xeeb nrog lub khob lub cev ua ntej muab khi.
Hauv qab Sealing thiab Stabilization
Kev tswj cov cua sov thiab siab yog siv los ua kom ruaj khov thiab xau- tiv taus lub khob puag.
Rim Curling txheej txheem
Lub khob ntug yog mechanically curled los txhim kho rigidity thiab txhim khu kev ua kom muaj zog.
Automatic Output thiab Stacking
Cov khob tiav tau sau thiab muab tso rau hauv lub thawv ntim thiab tuav.
Daim ntawv thov & Khoom siv sib xws
Compatible Materials Profiles
• Ob npaug -polyethylene (PE) coated khob Tshuag
• High-pab dej tsis sib haum-cov ntaub ntawv uas tiv taus
• PLA-coated biodegradable lossis laminated lwm cov khoom lag luam (raws li kev cai calibration)
Cov Khoom Siv Lub Hom Phiaj
• Ntim Cov Dej Txias: Cov dej qab zib muaj roj, cov kas fes khov, thiab cov dej qab zib.
• Frozen Dessert Dairy Cups: Ice creams, gelatos, khov yogurts, thiab sorbets.
• Condensation-Resistant Containers: High-moisture ib puag ncig uas yuav tsum tau tiv thaiv cov txheej txheem softening.
Vim li cas thiaj xaiv Sini Machinery
Sini Machinery tsom rau kev ruaj khov kho tshuab engineering rau daim ntawv khob tsim tshuab tsim los rau kev tsim khoom ib puag ncig.
Txhua lub tshuab yog tsim los nrog kev saib xyuas mus ntev - lub sij hawm ua hauj lwm zoo sib xws thiab ntau lawm efficiency.
• Cov ntsiab cai tseem ceeb ntawm engineering suav nrog:
• Kev ua haujlwm ruaj khov nyob rau hauv kev tsim khoom tsis tu ncua
• Ua raws li qhov tseeb ntawm cov khoom siv txuas ntxiv
• Tswj synchronization ntawm txhua qhov chaw nres tsheb
• Txhim khu kev tso zis zoo thoob plaws batch ntau lawm
• Adaptability rau cov ntawv coated sib txawv
Lub kaw lus yog tsim los txhawb kev tsim khoom ruaj khov thiab kwv yees kev tsim khoom lag luam.
Quality Assurance
Txhua lub tshuab raug tshuaj xyuas los ntawm cov txheej txheem kuaj ua ntej xa khoom:
Qhov no ua kom muaj kev ua tau zoo ib yam hauv qhov chaw tsim khoom tiag tiag.
OEM & Kev daws teeb meem
Sini Machinery muab customization raws li cov kev cai ntau lawm:
Customization ua kom muaj kev sib raug zoo nrog ntau cov tswv yim tsim khoom thiab cov chaw tsim khoom.
Certifications & Ntiaj teb no Export Experience
Sini Machinery tshuab yog tsim nyob rau hauv cov txheej txheem kev lag luam thiab xa mus rau ntau lub khw thoob ntiaj teb.
Kev them nyiaj yug muaj xws li:
Kev teeb tsa hluav taws xob rau cov qauv hauv cheeb tsam, suav nrog CE conformity thiab UL -cov khoom ua raws.
Muaj kev ruaj ntseg cov ntaub ntawv txhawb nqa
Kev txhawb nqa ntim rau kev thauj mus los thoob ntiaj teb
Installation thiab commissioning kev taw qhia
Cov khoom siv yog tsim los rau kev koom ua ke rau hauv kev tsim khoom thoob ntiaj teb nrog kev ua haujlwm ruaj khov.
Cov lus nug nquag
Thov ib qhov Project Quote
Maximize koj kab efficiency nrog ib tug optimized tsim hneev taw. Thov muab koj lub hom phiaj khob qhov ntev (Sab saum toj × Hauv qab × Qhov siab), koj nyiam ntawv GSM ntau yam, thiab koj muaj nyob rau hauv cheeb tsam lub zog specifications rau peb pab neeg ntawm Sini Machinery.
Peb pab neeg ua haujlwm engineering yuav npaj cov ncauj lus kom ntxaws txog kev siv tshuab, suav nrog kev kwv yees ntau lawm ceev thiab cov kev xaiv tsim nyog, los pab txhawb koj lub chaw tsim kho lub peev xwm.
Peb tau paub zoo-paub tias yog ib qho ntawm ob qho tib si pe paper cup forming tshuab manufacturers thiab lwm tus neeg nyob hauv Suav teb rau ntau tshaj 20 xyoo. Yog hais tias koj yuav mus yuav zoo siab ob chav pe ntawv khob txoj kev tshuab, txais tos kom tau txais cov lus hais los ntawm peb lub hoobkas. Rau nqe kev sab laj, tiv tauj peb.
